XV 270L/min High Pressure Jet Pump
XV
1 piece
Quantity:
- Min. Order: 1
- Specification Code: XV
- Specification Description: Cast Iron
Ultra High Pressure Pump
| XV Series High Pressure Plunger Pump | |||||||||
| Model | Flow Rate | Max Pressure | Speed | Power | Weight | ||||
| L/min | gpm | bar | p.s.i | Mpa | r.p.m | hp | kw | kg | |
| XV28 | 129 | 34 | 350 | 5075 | 35 | 1000 | 120 | 88 | 209 |
| XV32 | 168 | 44.9 | 250 | 3625 | 25 | 1000 | 113 | 83 | 209 |
| XV36 | 213 | 56.2 | 200 | 2800 | 20 | 1000 | 113 | 83 | 209 |
| XV40 | 270 | 71.3 | 180 | 2610 | 18 | 1000 | 127 | 93 | 209 |
XV Plunger Pump, also called shallow well pump, oil change pump, mud pump, mining slurry pump.
It is widely used in high pressure, large flow and occasions where the flow needs to be adjusted.
