HDP 105° Hot Water High Pressure Pump 30-52LPM 150BAR/2175PSI
HDP
minimum order
1
Quantity
- Min. Order: 1
- Specification Code: HDP
- Specification Description: Cast Iron
Plunger Pump
| HDP Series High Pressure Plunger Pump | |||||||||
| Model | Flow Rate | Max Pressure | Power | Speed | Plunger Dia | Stroke | |||
| L/min | gpm | bar | p.s.i | hp | kw | r.p.m | mm | mm | |
| HDP3015 | 30 | 7.93 | 150 | 2175 | 20 | 15 | 1450 | 28 | 11 |
| HDP4015 | 40 | 10.57 | 150 | 2175 | 20 | 15 | 1450 | 28 | 15 |
| HDP5215 | 52 | 13.74 | 150 | 2175 | 20 | 15 | 1450 | 28 | 21 |
The HDP hot water plunger pump,
also called pressure water pump, hot water pump, hot water system, heat pump efficiency, pumps for hot water, electric hot water system,
is a cold water spray plunger pump with a cast iron pump head.
It is best for medicine and chemical industry, seawater desalination equipment, fire fighting equipment and other application fields.
Our plunger pumps have a 1-2 year warranty. We provide 24/7 online technical support to provide you with considerate service.
