70-139L/min Plunger pump for fog cannon mistting gun
GT
Botuo GT Series high-pressure plunger pumps are suitable for environmental dusting, municipal cleaning, and garden humidification. Popular with consumers because of its excellent performance, GT series piston pumps have become the leader in the industry due to their easy installation and maintenance.
minimum order
1
Power
Flow rate
Quantity
Min. Order:1- Color:/
- Specification Code:GT
- Specification Description:CAST IRON
PLUNGER PUMP FOR FOG CANNON MISTTING GUN
GT Plunger Pump for dust removal, also called truck pump, industrial water pump, misting system pump.
It is widely used in high pressure, large flow and occasions where the flow needs to be adjusted.
| MODEL | Max Flow | Max Pressure | Speed | Power Require | Weight | ||||
| L/min | gpm | bar | p.s.i | Mpa | r.p.m | hp | kw | kg | |
| GT28 | 70 | 18.4 | 200 | 2900 | 20 | 1450 | 37 | 27 | 44 |
| 84 | 22.2 | 175 | 2538 | 17.5 | 1750 | 38 | 28 | 44 | |
| GT30 | 80 | 21.1 | 175 | 2538 | 17.5 | 1450 | 38 | 28 | 44 |
| 96 | 25.5 | 140 | 2030 | 14 | 1750 | 37 | 27 | 44 | |
| GT32 | 91 | 24 | 150 | 2175 | 15 | 1450 | 37 | 27 | 44 |
| GT36 | 115 | 30.4 | 120 | 1740 | 12 | 1450 | 38 | 28 | 44 |
| 139 | 36.7 | 100 | 1450 | 10 | 1750 | 38 | 28 | 44 | |
| GT40 | 142 | 37.5 | 100 | 1450 | 10 | 1450 | 38 | 28 | 44 |
| GT45 | 124 | 32.8 | 100 | 1450 | 10 | 1000 | 33 | 24 | 44 |
| 112 | 29.6 | 100 | 1450 | 10 | 900 | 30 | 22 | 44 | |
| 99 | 26.2 | 100 | 1450 | 10 | 800 | 27 | 20 | 44 | |
GT Plunger Pump for dust removal, also called truck pump, industrial water pump, misting system pump.
It is widely used in high pressure, large flow and occasions where the flow needs to be adjusted.
